型號

Type

額定電壓（Uo/U）kV

Rated Voltage

名稱

Designation

UGEFP

3.6/6  6/6  6/10  8.7/10  8.7/15  12/20  14/25

盾構機用電纜（露天礦用高壓橡套軟電纜）

UGEFHP

3.6/6  6/6  6/10  8.7/10  8.7/15  12/20  14/25

盾構機用耐寒電纜（露天礦用高壓耐寒橡套軟電纜）

芯數×標稱截面

Cores×Nor.

Cross-sectional

area mm²

 電纜近似外徑

Approx. overall

diameter

mm

20℃主線芯絕緣電阻

20℃ Phase Core Insulation Resistance

≥MΩ•km

電纜近似重量

kg/km

Approx. weight

kg/km

3×25+3×10

48.0-52.0

400

4245

3×35+3×10

51.0-56.0

360

4828

3×50+3×16

56.7-61.7

320

5670

3×70+3×16

61.2-66.2

280

7177

3×95+3×16

67.5-72.5

250

8337

3×120+3×25

70.7-75.7

230

9655

3×150+3×25

75.1-80.1

210

11661

3×185+3×35

81.2-86.2

190

13092

芯數×標稱截面

Cores×Nor.

Cross-sectional

area mm²

 電纜近似外徑

Approx. overall

diameter

mm

20℃主線芯絕緣電阻

20℃ Phase Core Insulation Resistance

≥MΩ•km

電纜近似重量

kg/km

Approx. weight

kg/km

3×10+1×10

48.9-52.9

550

3500

3×16+1×16

53.1-58.1

500

3834

3×25+3×10

49.7-54.7

450

4087

3×35+3×10

54.5-59.5

400

4979

3×50+3×16

58.4-63.4

350

5972

3×70+3×16

62.9-67.9

310

7134

3×95+3×16

69.2-74.2

280

8695

3×120+3×25

72.5-77.5

260

10096

3×150+3×25

78.6-83.6

230

11917

3×185+3×35

82.9-87.9

220

13721

芯數×標稱截面

Cores×Nor.

Cross-sectional

area mm²

 電纜近似外徑

Approx. overall

diameter

mm

20℃主線芯絕緣電阻

20℃ Phase Core Insulation Resistance

≥MΩ•km

電纜近似重量

kg/km

Approx. weight

kg/km

3×16+1×16

58.5-63.5

610

4648

3×25+3×10

56.2-61.2

550

5168

3×35+3×10

59.2-64.2

500

5861

3×50+3×16

63.1-68.1

440

7166

3×70+3×16

69.5-74.5

390

8771
